    GD25Q64ESIGR 64Mbit NOR Flash Memory IC with 133 MHz SPI - Quad I/O in 8-SOP Package for 2.7V ~ 3.6V Applications

    Ask Lasest Price
    Brand Name : Original Factory
    Model Number : GD25Q64ESIGR
    Certification : Lead free / RoHS Compliant
    Price : Contact for Sample
    Payment Terms : T/T,L/C,Western Union
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    GD25Q64ESIGR 64Mbit NOR Flash Memory IC with 133 MHz SPI - Quad I/O in 8-SOP Package for 2.7V ~ 3.6V Applications

    GD25Q64ESIGR Memory IC Chip 64Mbit NOR Flash Memory IC SOP8 Serial Flash Memory​


    Product Description Of GD25Q64ESIGR

    GD25Q64ESIGR is 64Mbit, Serial NOR Flash Memory IC, it supports the standard Serial Peripheral Interface (SPI), and the Dual/Quad SPI: Serial Clock, Chip Select, Serial Data I/O0 (SI), I/O1 (SO), I/O2 (WP#), I/O3 (HOLD#). The Dual I/O data is transferred with speed of 266Mbit/s, and the Quad I/O data is transferred with speed of 532Mbit/s.


    Specification Of GD25Q64ESIGR

    Memory Type
    Non-Volatile
    Memory Format
    FLASH
    Technology
    FLASH - NOR
    Memory Size
    64Mbit
    Memory Organization
    8M x 8
    Memory Interface
    SPI - Quad I/O
    Clock Frequency
    133 MHz
    Write Cycle Time - Word, Page
    70µs, 2.4ms
    Access Time
    7 ns
    Voltage - Supply
    2.7V ~ 3.6V
    Operating Temperature
    -40°C ~ 85°C (TA)
    Mounting Type
    Surface Mount
    Package / Case
    8-SOIC (0.209", 5.30mm Width)
    Supplier Device Package
    8-SOP


    Features Of GD25Q64ESIGR

    64M-bit Serial Flash
    - 8192K-Byte
    - 256 Bytes pe
    Standard, Dual, Quad SPI
    - Standard SPI: SCLK, CS#, SI, SO, WP#, HOLD#
    - Dual SPI: SCLK, CS#, IO0, IO1, WP#, HOLD#
    - Quad SPI: SCLK, CS#, IO0, IO1, IO2, IO3
    High Speed Clock Frequency
    - 133MHz for fast read
    - Dual I/O Data transfer up to 266Mbits/s
    - Quad I/O Data transfer up to 532Mbits/s
    Fast Program/Erase Speed
    - Page Program time: 0.5ms typical
    - Sector Erase time: 45ms typical
    - Block Erase time: 0.15s/0.25s typical
    - Chip Erase time: 25s typical
    Flexible Architecture
    - Uniform Sector of 4K-Byte
    - Uniform Block of 32/64K-Byte
    Low Power Consumption
    - 12μA typical standby current
    - 1μA typical deep power down current
    Advanced Security Features
    - 128-bit Unique ID for each device
    - Serial Flash Discoverable parameters (SFDP) register
    - 3x1024-Byte Security Registers With OTP Locks
    Single Power Supply Voltage
    - Full voltage range: 2.7-3.6V
